Manual:IPv6/ND
Summary
Sub-menu: /ipv6 nd
Standards: RFC 2462, RFC 2461
Package : IPv6
RadioOS has Ipv6 Neighbor Detection and stateless address autoconfiguration support using Router Advertisement Daemon (RADVD).
Node description
Node is a device that implements IPv6. In IPv6 networks nodes are divided into two types:
- Routers - a node that forwards IPv6 packets not explicitly addressed to itself.
- Hosts - any node that is not a router.
Routers and hosts are strictly separated, meaning that router cannot be host and host cannot be router at the same time.
Stateless address autoconfiguration
There are several types of autoconfiguration:
- stateless - address configuration is done by received Router Advertisement messages. These messages include stateless address prefixes and require that host is not using stateful address configuration protocol.
- stateful - address configuration is done by using stateful address configuration protocol (DHCPv6). Stateful protocol is used if RA messages do not include address prefixes.
- both - RA messages include stateless address prefixes and require that hosts use a stateful address configuration protocol.
A highly useful feature of IPv6 is the ability to automatically configure itself without the use of a stateful configuration protocol like DHCP ( See example).
It is called stateless address autoconfiguration, since there is no need to manage state in the router side. It is a very simple, robust and effective autoconfiguration mechanism.
RadioOS uses RADVD to periodically advertise information about the link to all nodes on the same link. The information is carried by ICMPv6 "router advertisement" packet, and includes following fields:
- IPv6 subnet prefix
- Default router link local address
- Other parameters that may be optional: link MTU, default hoplimit, and router lifetime.
Then host catches the advertisement, and configures the global IPv6 address and the default router. Global IPv6 address is generated from advertised subnet prefix and EUI-64 interface identifier.
Optionally, the host can ask for an advertisement from the router by sending an ICMPv6 "router solicitation" packet. On linux rtsol utility transmits the router solicitation packet. If you are running a mobile node, you may want to transmit router solicitations periodically.
Note: Due to restrictions of IPv6, address auto-configuration can not be performed on routers. Routers require manual address configuration.
Address states
When auto-configuration address is assigned it can be in one of the following states:
tentative
- in this state host verifies that the address is unique. Verification occurs through duplicate address detection.preferred
- at this state address is verified as unique and node can send and receive unicast traffic to and from a preferred address. The period of time of preferred state is included in the RA message.deprecated
- address is still valid, but is not used for new connections.invalid
- node can no longer send or receive unicast traffic. An address enters the invalid state after the valid lifetime expires.
Image below ilustrates relation between states and lifetimes.
Neighbor discovery
Sub-menu: /ipv6 nd
In this submenu IPv6 Neighbor Discovery (ND) protocol is configured.
Neighbor Discovery (ND) is a set of messages and processes that determine relationships between neighboring nodes. ND, compared to IPv4, replaces Address Resolution Protocol (ARP), Internet Control Message Protocol (ICMP) Router Discovery, and ICMP Redirect and provides additional functionality.
ND is used by hosts to:
- Discover neighboring routers.
- Discover addresses, address prefixes, and other configuration parameters.
ND is used by routers to:
- Advertise their presence, host configuration parameters, and on-link prefixes.
- Inform hosts of a better next-hop address to forward packets for a specific destination.
ND is used by nodes to:
- Both resolve the link-layer address of a neighboring node to which an IPv6 packet is being forwarded and determine when the link-layer address of a neighboring node has changed.
- Determine whether IPv6 packets can be sent to and received from a neighbor.
Properties
Property | Description |
---|---|
advertise-dns (yes | no; Default: no) | Option to redistribute DNS server information using RADVD. You will need a running client side software with Router Advertisement DNS support to take advantage of the advertised DNS information. Read more >> |
advertise-mac-address (yes | no; Default: yes) | When set, the link-layer address of the outgoing interface is included in the RA. |
comment (string; Default: ) | Descriptive name of an item |
disabled (yes | no; Default: no) | Whether item is disabled or not. By default entry is enabled. |
hop-limit (unspecified | integer[0..4294967295]; Default: unspecified) | The default value that should be placed in the Hop Count field of the IP header for outgoing (unicast) IP packets. |
interface (all | string; Default: ) | Interface on which to run neighbor discovery.
|
managed-address-configuration (yes | no; Default: no) | Flag indicates whether hosts should use stateful autoconfiguration (DHCPv6) to obtain addresses. |
mtu (unspecified | integer[0..4294967295]; Default: unspecified) | The MTU option is used in router advertisement messages to insure that all nodes on a link use the same MTU value in those cases where the link MTU is not well known.
|
other-configuration (yes | no; Default: no) | Flag indicates whether hosts should use stateful autoconfiguration to obtain additional information (excluding addresses). |
ra-delay (time; Default: 3s) | The minimum time allowed between sending multicast router advertisements from the interface. |
ra-interval (time[3s..20m50s]-time[4s..30m]; Default: 3m20s-10m) | min-max interval allowed between sending unsolicited multicast router advertisements from the interface. |
ra-lifetime (none | time; Default: 30m) | |
reachable-time (unspecified | time[0..1h]; Default: unspecified) | The time that a node assumes a neighbor is reachable after having received a reachability confirmation. Used by the Neighbor Unreachability Detection algorithm (see Section 7.3 of RFC 2461) |
retransmit-interval (unspecified | time; Default: unspecified) | The time between retransmitted Neighbor Solicitation messages. Used by address resolution and the Neighbor Unreachability Detection algorithm (see Sections 7.2 and 7.3 of RFC 2461) |
Prefix
Sub-menu: /ipv6 nd prefix
Prefix information sent in RA messages used by stateless address auto-configuration.
Properties
Property | Description |
---|---|
6to4-interface (none | string; Default: ) | If this option is specified, this prefix will be combined with the IPv4 address of interface name to produce a valid 6to4 prefix. The first 16 bits of this prefix will be replaced by 2002 and the next 32 bits of this prefix will be replaced by the IPv4 address assigned to interface name at configuration time. The remaining 80 bits of the prefix (including the SLA ID) will be advertised as specified in the configuration file. |
autonomous (yes | no; Default: yes) | When set, indicates that this prefix can be used for autonomous address configuration. Otherwise prefix information is silently ignored. |
comment (string; Default: ) | Descriptive name of an item |
disabled (yes | no; Default: no) | Whether item is disabled or not. By default entry is enabled. |
on-link (yes | no; Default: yes) | When set, indicates that this prefix can be used for on-link determination. When not set the advertisement makes no statement about on-link or off-link properties of the prefix. For instance, the prefix might be used for address configuration with some of the addresses belonging to the prefix being on-link and others being off-link. |
preferred-lifetime (infinity | time; Default: 1w) | Timeframe (relative to the time the packet is sent) after which generated address becomes "deprecated". Deprecated is used only for already existing connections and is usable until valid-lifetime expires. Read more >> |
prefix (ipv6 prefix; Default: ::/64) | Prefix from which stateless address autoconfiguration generates the valid address. |
valid-lifetime (infinity | time; Default: 4w2d) | The length of time (relative to the time the packet is sent) an address remains in the valid state. The valid-lifetime must be greater than or equal to the preferred-lifetime. Read more >> |
interface (string; Default: ) | Interface name on which stateless auto-configuration will be running. |
Examples
Stateless autoconfiguration example
[admin@CableFree] > ipv6 address print Flags: X - disabled, I - invalid, D - dynamic, G - global, L - link-local # ADDRESS INTERFACE ADVERTISE 0 G 2001:db8::1/64 ether1 yes
As in example above advertise flag is enabled which indicates that dynamic /ipv6 nd prefix
entry is added.
[admin@CableFree] > ipv6 nd prefix print Flags: X - disabled, I - invalid, D - dynamic 0 D prefix=2001:db8::/64 interface=ether1 on-link=yes autonomous=yes valid-lifetime=4w2d preferred-lifetime=1w
On a host that is directly attached to the router we see that an address was added. The address consists of prefix part (first 64 bits) that takes prefix from the prefix advertisement, and host part (last 64 bits) that is automatically generated from local MAC address:
atis@atis-desktop:~$ ip -6 addr 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 16436 inet6 ::1/128 scope host valid_lft forever preferred_lft forever 2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qlen 1000 inet6 2001:db8::21a:4dff:fe56:1f4d/64 scope global dynamic valid_lft 2588363sec preferred_lft 601163sec inet6 fe80::21a:4dff:fe56:1f4d/64 scope link valid_lft forever preferred_lft forever
The host has received the 2001:db8::/64 prefix from the router and configured an address with it.
There is also an option to redistribute DNS server information using RADVD:
[admin@CableFree] > ip dns set server=2001:db8::2 [admin@CableFree] > ip dns print servers: 2001:db8::2 ... [admin@CableFree] > ipv6 nd set [f] advertise-dns=yes
You will need a running client side software with Router Advertisement DNS support to take advantage of the advertised DNS information.
On Ubuntu/Debian linux distributions you can install rdnssd package which is capable of receiving advertised DNS address.
mrz@bumba:/$ sudo apt-get install rdnssd
mrz@bumba:/$ cat /etc/resolv.conf # Dynamic resolv.conf(5) file for glibc resolver(3) generated by resolvconf(8) # DO NOT EDIT THIS FILE BY HAND -- YOUR CHANGES WILL BE OVERWRITTEN nameserver 2001:db8::2 mrz@bumba:/$ ping6 www.CableFree.net PING www.CableFree.net(2a02:610:7501:1000::2) 56 data bytes 64 bytes from 2a02:610:7501:1000::2: icmp_seq=1 ttl=61 time=2.11 ms 64 bytes from 2a02:610:7501:1000::2: icmp_seq=2 ttl=61 time=1.33 ms ^C --- www.CableFree.net ping statistics --- 2 packets transmitted, 2 received, 0% packet loss, time 1001ms rtt min/avg/max/mdev = 1.334/1.725/2.117/0.393 ms mrz@bumba:/$
